18.5in Industrial Android Tablet 1000nits 1920×1080 RFID NFC

  • 18.5in Industrial Android Tablet 1000nits 1920×1080 RFID NFC
  • 18.5in Industrial Android Tablet 1000nits 1920×1080 RFID NFC
  • 18.5in Industrial Android Tablet 1000nits 1920×1080 RFID NFC
Place of Origin China
Brand Name ITD/OEM
Certification CE, FCC, RoHS
Model Number ITD18PPCT5LE1
Minimum Order Quantity 1PCS
Price TBA
Packaging Details 1-5pcs/CTN, Safe, Firm, suitable for international shipping
Delivery Time 15-20 Business Days
Payment Terms T/T, Western Union, Paypal
Supply Ability 10000PCS/Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Native Resolution 1920×1080 Brightness 1000nits, 1500nits Optional
Processor ARM RK3288, RK3399 Android 9/10/11,Ubuntu Touch Panel Capacitive, PCAP, Restive, IR Touch
Optional 4G, BT, WIFI, RFID/NFC I/O USB, COM, HDMI, Audio, LAN, DC 12V Input
Operating Temperature -20~70℃ Storage Temperature -20~70℃
Material Chassis Steel Housing MTBF 50000hours
Highlight

18.5in Industrial Android Tablet

,

1000nits Industrial Android Tablet

,

RFID NFC Android Touch Pc
Leave a Message
Product Description

1000nits 1920×1080 18.5inch industrial chassis android tablet -20~70℃



The ITD industrial chassis panel PC is fully-integrated that combines high-performance ARM based or x86 based PC system with Projected Capacitive Touch (PCT or PCAP)/Resistive Touch/IR Touch/SAW Touch Technology optional in a industrial-grade high bright TFT-LCD flat panel with rugged chassis design. The ITD Windows-based control panel is Commercial Off-the-Shelf (COTS) unit and allows easy access to touch capabilities built into Windows 7/8/10 and other popular programming languages. The ITD chassis panel PC is designed for industrial, process manufacturing, discrete manufacturing, industrial automation, building automation, process control, access control, room reservation, room scheduling, medical healthcare, kiosks, machinery manufacturing, and custom machine to machine interface applications.



FEATURES

• Flexible, reliable, and ruggedized for open platform HMI/SCADA
• Energy-efficient and fan-less HMI Systems
• Low cost solution with high cost-efficient
• All steel construction designed for harsh and industrial environments

• Flexible, easy configuration and integration
• CE, FCC, RoHS Compliance



OPTIONALS

• Anti-Glare / Anti-Reflective Tempered Glass • 1500nits, Optical Bonding
• Resistive, IR, SAW, PCAP, SLW • WIFI, 3G, 4G
• Web camera, Speakers, RFID, NFC, Fingerprint, QR Reader, Thermal printer, GPS etc. • DC9-36V input, AC100-240V input

DISPLAY

Panel Cell Type/Glass Surface TFT
Size/ Aspect Ratio 18.5”/16:9
Active Area/ Pixel Pitch 412.6(H) x 233.2(V)mm/0.300× 0.300mm
Native Resolution/ Colors 1366 x 768(1920 x 1080 optional)/16.7M
Brightness/ Contrast 1000cd/㎡/1000:1
Response Time/ Viewing Angle(Typical) 14ms/85/85/80/80
Light Source LED Backlight with 50000Hours’Lifetime

SYSTEM

Item Android Solution X86 Solution 1 X86 Solution 2
CPU ARM Quad Core Cortex-A17, 1.8GHz Intel® Celeron J1900 2.0GHz Intel® Core i3/i5/i7
Chipset RK3288(RK3399 optional) Intel Bay Trail SoC Intel SoC Chipset
Memory 2GB; 4GB Optional Dual Channel, DDR3 1333/1600MHz Memory, Max.8GB 2 x DDR3 1333/1600MHz SO-DIMM Slot, Max. 16GB
Storage 8GB: 16GB/32GB/64GB Optional 1 x SATA, 1 x mSATA, Default to 64GB SSD 1 x SATA, 1 x mSATA, Default to 64GB SSD
Graphics Supports max. 4K resolution Intel HD Graphics (By CPU) Intel HD Graphics (By CPU)
I/O 1 × HDMI; 2 × USB Max. 4× USB; 1 × USB OTG(Optional); 2 × COM; 1 × TF Card Slot Support 8~128GB

1 x VGA Output; 1 x HDMI Output; 2 x USB 3.0; 2 x USB 2.0 max. 6; COM port(optional); 1 x Realtek ALC662

Line-Out /MIC IN

1 x VGA Output; 1 x HDMI Output; 2 x USB 3.0; 2 x USB 2.0 max. 6; 2 x COM max. 6; 1 x Realtek ALC662

Line-Out /MIC IN
LAN 1 x 10/100/1000Mbps Ethernet 1 x 10/100/1000Mbps Ethernet 1 x 10/100/1000Mbps Ethernet
OS Android 6.0 (Android 7.0 optional) Windows 7/8/10, Linux Windows 7/8/10, Linux

GENERAL

Power Input Voltage DC 12V 2.0
Operation/Power Saving 30~55W
Environment Considerations Operating Temperature -10~60℃
Storage Temperature -20~70℃
Relative Humidity 10%~90% (Non-Condensing)



18.5in Industrial Android Tablet 1000nits 1920×1080 RFID NFC 0

18.5in Industrial Android Tablet 1000nits 1920×1080 RFID NFC 1
