Waterproof IP65 Touch Screen PC Intel Skylake Core 19" Rugged Touch Screen Computer
| Place of Origin | China |
|---|---|
| Brand Name | ITD/OEM |
| Certification | CE/ROHS/FCC |
| Model Number | ITD19PPCT1IPSI5-69K |
| Minimum Order Quantity | 1PCS |
| Price | TBA |
| Packaging Details | Foam,gift box,master carton,wooden case,pallet |
| Delivery Time | 1 month |
| Payment Terms | T/T, Western Union,Paypal |
| Supply Ability | 10000 unit per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| CPU | Intel Skylake Core I3/i5/i7 | Material | Stainless Steel Housing 304 Or 316L |
|---|---|---|---|
| Screen Diagonal | 19" | Physical Resolution | 1280×1024 |
| Waterproof I/O | 1 X LAN, 2 X USB, 1 X COM, 1 X Power (IP66 Connectors) | Operating Temp | -10 To 60℃, -20 To 70℃ Optional |
| OS | Windows 7/10/Linux | Aging Test | Above 48h |
| MTBF | 50000hous | Warranty | 2 Years |
| Highlight | Waterproof IP65 Touch Screen PC,Rugged IP65 Touch Screen PC,Intel Skylake Rugged Touch Screen Computer |
||
Product Description
IP65 IP66 waterproof touch screen computer Intel Skylake Core i3i5i7 19" for food beverage industry
Key Highlights
- ●19" 4:3 Ratio Touchscreen
- ●6th Gen Intel Skylake Core i3/i5/i7 CPU
- ●Flat Wireless WiFi/BT Antenna
- ●Full IP66 and IP69K with Optional IP67
- ●Optional Speakers, RFID/NFC reader and Barcode Reader
| Panel | Cell Type/Glass Surface | TFT LCD |
| Aspect Ratio/Size | 19” 4:3 | |
| Active Area | 376.32(H) x 301.056(V)mm | |
| Pixel Pitch | 0.294(H) x 0.294(V)mm | |
| Native Resolution | 1280 x 1024 | |
| Contrast | 1000:1 | |
| Colors | 16.7M | |
| Contrast Ratio | 250nits, 1000nits optional | |
| Response Time | 3.6/1.4ms | |
| Viewing Angle (Typical) | 85/85/80/80 | |
| Light Source | LED Backlight with 50000Hours’ Lifetime | |
| System | CPU | Intel® Skylake Core i3/i5/i7 Processor |
| BIOS | AMI | |
| Chipset | Intel® SOC CPU Integrated | |
| Memory | 2 x SO-DIMM, DDR3 1333MHz Memory, 2GB, Max.16GB | |
| Graphic Chipset | CPU integrated graphics HD and support 1080p | |
| Storage | SSD/HDD | |
| I/O | Serial Ports | 1x COM (Optional) |
| USB Ports | 2 x USB 2.0(Waterproof Connector and Cable) | |
| Power Port | 1 x 12V DC Jack (Waterproof Connector and Cable) | |
| LAN | 1 x 10/100/1000Mbps Ethernet (Waterproof Connector and Cable) | |
| WIFI | Built-in, 802.11a/b/g/h (optional) | |
| Touch Screen | Type | Projected Capacitive Touch Screen with 10 independent touch points |
| Response Time | ≤5ms | |
| Transparency | ≥85% | |
| Lifetime | ≥50,000,000 times/click | |
| OS Support | Windows CE/XP/7/8/10, Linux, Mac, Android | |
| General | Power Input | DC 12V |
| Power Switch | Optional | |
| Mounting | 100 x 100mm VESA Mount | |
| Operation/Power Saving | 42W | |
| Operating Temperature | -10~60℃, -20~70℃ optional | |
| Storage Temperature | -20~70℃ | |
| OS Support | Windows 7/ Windows XP/ Windows 8/Window 10/ Linux | |
