IP67 Rugged Panel PC 7" Computers Touch Screen Intel I5 10210u
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| CPU | Intel Core I5-210u, Comet Lake | Material | Stainless Steel Housing 304, 316L |
|---|---|---|---|
| Screen Diagonal | 7" | Waterproof I/Os | 1 X COM, 2 X USB, 1 X LAN, 1x DC M12 Connectors |
| IP Rate | IP67 | Operating Temp | -10 To 60℃, -20 To 70℃ Optional |
| Touch Screen | Resistive/capacitive Touch | Brightness | 500nits, 1000nits Optional |
| MTBF | 50000hours | Applications | Pharmacy Industry, Food And Beverage Processing Plants |
| Highlight | IP67 Rugged Panel PC,10210u Rugged Panel PC,10210u Computers Touch Screen |
||
Product Description
IP67 Rugged Panel PC 7" Computers Touch Screen Intel I5 10210u
rugged industrial computers touch screen IP67 7" Intel i5 10210u
ITD's 7" rugged industrial computers touch screen IP67 is commonly used in industries such as marine, outdoor, and industrial environments where exposure to moisture, dust, and extreme temperatures is common. It typically features a touch screen display, a powerful processor, and a range of connectivity options including Wi-Fi, Ethernet, and USB. With its waterproof and dustproof design, an IP67 panel PC can operate reliably even in the harshest conditions, making it an ideal choice for applications that require rugged and dependable computing solutions.
Features of rugged industrial computers
-
High durability: The stainless steel construction of the device makes it highly resistant to corrosion, impact, and other forms of physical damage.
-
Water and dust resistance: The device is completely protected against dust ingress and can withstand being submerged in water up to 1 meter for 30 minutes. It can also withstand high-pressure, high-temperature washdowns.
-
Connectivity options: IP67 panel PCs typically offer a range of connectivity options, including Wi-Fi, Ethernet, USB, and serial ports.
-
Wide operating temperature range: To ensure reliable performance in extreme temperatures, an IP67 panel PC is designed to operate in a wide temperature range, typically from -20°C to +60°C.
-
Fanless design: Many IP67 panel PCs are designed to be fanless, which eliminates the risk of dust and moisture entering the system and also reduces noise.
-
High level of customization: IP67 panel PCs are available in a wide range of sizes, configurations, and options, allowing for a high level of customization to meet specific application requirements.
Specifiction of of rugged industrial computers
| Panel | Cell Type/Glass Surface | TFT |
| Size/ Aspect Ratio | 7”/16:9 | |
| Active Area/ Pixel Pitch | 154.214(W) x 85.49(H)mm/0.150 × 0.150mm | |
| Native Resolution/ Colors | 1024 x 600/262K/16.7M | |
| Brightness/ Contrast | 400cd/㎡/800:1 | |
| Response Time/ Viewing Angle(Typical) | 10/15ms/75/75/70/75 | |
| Light Source | LED Backlight with 50000Hours’Lifetime |
SYSTEM
| Item | Android Solution | X86 Solution 1 | X86 Solution 2 |
| CPU | ARM Quad Core Cortex-A17, 1.8GHz (RK3399 optional) | Intel® Celeron J1900 2.0GHz | Intel® Core i3/i5/i7 |
| Chipset | RK3288 | Intel Bay Trail SoC | Intel SoC Chipset |
| Memory |
2GB; 4GB Optional
|
Dual Channel, DDR3 1333/1600MHz Memory, Max.8GB |
2 x DDR3 1333/1600MHz SO-DIMM Slot, Max. 16GB |
| Storage | 8GB: 16GB/32GB/64GB Optional | 1 x SATA, 1 x mSATA, Default to 64GB SSD | 1 x SATA, 1 x mSATA, Default to 64GB SSD |
| Graphics | Supports max. 4K resolution | Intel HD Graphics (By CPU) | Intel HD Graphics (By CPU) |
| Default Waterproof I/O |
2 × USB, 1× RJ45, 1× DC12V. COM ports, HDMI Output, Audio, etc. optional |
2 × USB, 1× RJ45, 1× DC12V. COM ports, HDMI Output, Audio, etc. optional |
2 × USB, 1× RJ45, 1× DC12V. COM ports, HDMI Output, Audio, etc. optional |
| LAN | 1 x 10/100/1000Mbps Ethernet | 1 x 10/100/1000Mbps Ethernet | 1 x 10/100/1000Mbps Ethernet |
| OS | Android 6.0 (Android 7.0 optional) | Windows 7/8/10, Linux | Windows 7/8/10, Linux |
GENERAL
| Power | Input Voltage | DC 12V 2.0 |
| Operation/Power Saving | 10~30W | |
| Environment Considerations | Operating Temperature | -10~60℃(-20~70℃ optional) |
| Storage Temperature | -20~70℃ | |
| Mounting | 75 x 75 VESA Mount, Panel/Embedded Mount optional | |
Display of of rugged industrial computers touch screen
