Embedded Touch Screen Panel PC 19'' Intel Core I5-7200U 2.5GHz TFT LCD Industrial PC
| Place of Origin | China |
|---|---|
| Brand Name | ITD/OEM |
| Certification | CE/ROHS/FCC |
| Model Number | ITD19PPCT5X** |
| Minimum Order Quantity | 1PCS |
| Price | TBA |
| Packaging Details | Foam,gift box,master carton,wooden case,pallet |
| Delivery Time | 15-20 work days |
| Payment Terms | T/T, Western Union,Paypal |
| Supply Ability | 10000 unit per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| CPU | Intel® Core™ Processor I5-7200U | Size | 19" |
|---|---|---|---|
| Active Area | 376.32(H) X 301.06(V)mm | Native Resolution | 1280X1024 |
| Brightness | 250cd/m2 | Viewing Angle | 85/85/85/85 |
| Input Voltage | DC9-36V，DC12V | ||
| Highlight | Embedded Touch Panel PC 19in,2.5GHz Touch Screen Panel PC |
||
Product Description
Embedded Touch Screen Panel PC 19'' Intel Core i5-7200U 2.5GHz
The ITD industrial multi-touch screen panel mounted panel PC is fully-integrated‚ multi capacitive touch screen that combines high-performance Intel® Celeron™ Quad Core Processor J1900 2.0 GHz with Projected Capacitive Touch (PCT or PCAP) Technology in a sleek industrial-grade IP65/ NEMA 4/4x Ingress rating TFT-LCD flat panel with flat front surface design. The ITD Windows-based control panel is Commercial Off-the-Shelf (COTS) unit and allows easy access to ten-touch capabilities built into Windows 7/8 and other popular programming languages. The ITD multi-touch panel mounted panel PC is designed for industrial, process manufacturing, discrete manufacturing, industrial automation, building automation, process control, access control, room reservation, room scheduling, medical healthcare, kiosks, machinery manufacturing, and custom machine to machine interface applications.
Specs:
| Panel | Cell Type/Glass Surface | TFT LCD |
| Size | 19” | |
| Aspect Ratio | 4:3 | |
| Active Area | 376.32(H) x 301.06(V)mmmm | |
| Pixel Pitch | 0.294 x 0.294mm | |
| Native Resolution | 1280 x 1024 | |
| Colors | 262K | |
| Brightness | 250cd/㎡ | |
| Contrast | 800:1 | |
| Response Time | 25ms | |
| Viewing Angle(Typical) | 85/85/85/85 | |
| Light Source | LED Backlight with 50000Hours’Lifetime |
SPECIFICATION
| System | CPU | Intel® Core Quad Core i5-7200U 2.5GHz Fanless |
| BIOS | AMI | |
| Chipset | Intel H110 | |
| Memory | 2 x SO-DIMM, DDR4 2133/2400MHz Memory, 8GB, Max.32GB | |
| Graphic Chipset | Intel HD Graphics 620 | |
| Storage | 2 x SATA3.0 1 x mSATA (SATA SSD) | |
| LAN | 2 x 10/100/1000Mbps Ethernet | |
| Input / Output | Serial Ports | 1 x COM |
| USB Ports | 4 X USB | |
| VGA Port | 1 x VGA | |
| HDMI Port | 1x HDMI Port | |
| Audio Card |
with Realtek ALC662 Line-Out /MIC IN |
|
| Power | Input Voltage | DC 9-36V |
| Operation/Power Saving | 30W | |
| Environment Considerations | Operating Temperature | -10~60℃ |
| Storage Temperature | -20~70℃ | |
| Relative Humidity | 10%~90% (Non Condensing) | |
| Anti-Vibration | 5Hz-500Hz / 1Grms/3 Axis | |
| Anti-Shock | 15G, 15ms Duration |
Image:
FEATURES
▪ Freescale ARM Cortex-A9 i.MX 6DualLite processor with Android 5.1 OS
▪ LTE/HSPA+, Wi-Fi, Bluetooth, and GPS connectivity
▪ Energy-efficient and fan-less HMI Systems
▪ Robust design with aluminum bezel NEMA 4/ IP65 front panel
▪ CAN bus interface with raw CAN, J1939, and OBD-II/ISO 15765 support
