43 Inch Open Frame LCD Monitor DVI and LVDS Panel Interface for Enhanced Visibility
| Place of Origin | China |
|---|---|
| Brand Name | ITD |
| Certification | CE,ROHS,FCC |
| Model Number | ITD43OFN1KTxx |
| Document | ITD43OFN1KTxx.pdf |
| Minimum Order Quantity | 1 |
| Packaging Details | foam,master carton |
| Delivery Time | a month |
| Payment Terms | T/T in advance |
| Supply Ability | 1000pcs/month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Screen Size | 43" | Brightness | 1000~3000 Cd/m2 |
|---|---|---|---|
| Panel Interface | LVDS | AD Board Interface | VGA,DVI,HDMI |
| Resolution | 1920*1080 | Response Time | 9ms |
| VESA | 400×250mm | ||
| Highlight | DVI Open Frame LCD Monitor,LVDS Open Frame LCD Monitor,43 Inch Open Frame LCD Monitor |
||
Product Description
Hi Tni panel 1000-3500 nits 43 inch open frame lcd monitor enhancing visibility
The ITD43OFN1KTxx is a 32 inch sunlight readable industrial grade open frame LCD, with high brightness 1000~3000 nits and high color saturation, it produces sharp images, crisp text and lifelike colors. The LED backlight technology ensures high reliability and low power consumption, widely used for outdoor application, such as outdoor totem, outdoor kiosk, factory automation, military, transportation.
Specification sheet
| Model | ITD43OFN1KTxx |
| Description | 43” Open Frame High Brightness LCD Monitor |
| Screen Size | 43” |
| Display Area(mm) | 941.18(H)×529.42(V) |
| Brightness | 1000~3500 cd/㎡ |
| Resolution | 1920×1080 |
| Aspect Ratio | 16:9 |
| Contrast Ratio | 1400:1 |
| Pixel Pitch(mm) | 0.63(H)×0.63(V) |
| Viewing Angle | 178°(H),178°(V) |
| Color Saturation(NTSC) | 76% |
| Display Color | 16.7M |
| Response Time(Typical) | 9ms |
| Panel Interface | LVDS |
| AD Board interface | VGA,DVI,HDMI |
| Input Power | AC90-132V/180-264V |
| Power consumption | 180~260W |
| Dimensions(mm) | 974×568×93 |
| Weight(Net) | 17kg |
| Mounting | VESA 400×250mm |
| Operating Temperature | -20°C ~ 70°C |
| Storage Temperature | -20°C ~ 70°C |
| Order Information | 43” 1000nits Open Frame LCD Monitor/ITD43OFN1KT02 |
| 43” 1500nits Open Frame LCD Monitor/ITD43OFN1KT01 | |
| 43” 2000nits Open Frame LCD Monitor/ITD43OFN1KT03 | |
| 43” 2500nits Open Frame LCD Monitor/ITD43OFN1KT04 | |
| 43” 3000nits Open Frame LCD Monitor/ITD43OFN1KT05 | |
| 43” 3500nits Open Frame LCD Monitor/ITD43OFN1KT06 | |
| 43” High Brightness Open Frame LCD Monitor with PCAP Touch/ITD43OFT5KTxx |
Key Features
--High brightness: 1000-3500 nits
--Sunlight readable
--LED backlight
--Slim Bezel
--Low power consumption
--High color saturation
--Touch screen optional
